CommScope CS37P Cat6 Plenum 23AWG White Solid Copper 1000ft Cable

CommScope CS37P Cat6 Plenum Cable - ETL Verified U/UTP 1000ft Ethernet Cable

The CommScope CS37P is a premium Category 6 unshielded twisted pair (U/UTP) plenum-rated cable designed for high-performance network installations. This ETL-verified cable delivers exceptional data transmission capabilities up to 400 MHz, making it ideal for demanding commercial and residential applications. With its white jacket and 1000ft length on a convenient reel, the CS37P offers the perfect balance of performance, compliance, and installation flexibility for modern networking infrastructure. Engineered to meet or exceed ANSI/TIA-568.2-D standards, this horizontal cable ensures reliable connectivity for your most critical network deployments.

Product Specifications

• Part Number: CS37P
• Classification: Category 6 U/UTP Cable, Plenum-rated
• Color: White jacket
• Length: 1000 ft (305 m) Reelex
• Conductor Type: Solid copper, 23 AWG
• Conductor Count: 8 conductors (4 pairs)
• Separator Type: FEP isolator
• Diameter: 5.639 mm (0.222 in) nominal over jacket
• Maximum Operating Frequency: 400 MHz
• Maximum Operating Voltage: 80V
• Safety Voltage Rating: 300V
• Nominal Velocity of Propagation (NVP): 75%
• Maximum Pulling Tension: 25 lb (11.34 kg)

Performance Features

• Superior Transmission: Supports data rates up to 10 Gbps (at distances up to 55 meters) with minimal signal loss
• Enhanced Crosstalk Protection: Advanced design minimizes NEXT (Near End Crosstalk) for clearer signal transmission
• Excellent Return Loss: Optimized impedance matching reduces signal reflections
• Low Delay Skew: Maximum 45 ns delay skew ensures synchronized data transmission
• Power over Ethernet Compatibility: Fully complies with IEEE 802.3bt (Type 4) for safe power delivery over LAN cables
• Comprehensive Testing: All electrical transmission tests include swept frequency measurements for guaranteed performance

Applications & Uses

Commercial Installations

The CS37P excels in business environments where reliable, high-speed connectivity is essential. Perfect for:

• Corporate office networks
• Data centers and server rooms
• Educational institutions
• Healthcare facilities
• Government buildings
• Retail environments

Residential Networking

This cable provides exceptional performance for home networking applications, supporting:

• High-speed internet connectivity
• Smart home systems
• Home entertainment networks
• Multi-room streaming services
• Gaming setups requiring low latency connections

Network Infrastructure

The CommScope CS37P is ideal for various network infrastructure components:

• Horizontal cabling runs
• Backbone connections
• Telecommunications rooms
• Equipment connections
• Wireless access point feeds
• Security and surveillance systems

Construction & Materials

The CS37P features premium construction elements that ensure durability and performance:

• Conductors: Bare copper for optimal conductivity
• Insulation: FEP and Polyolefin materials for superior electrical properties
• Jacket: PVC material designed for plenum environments
• Separator: FEP material maintains pair geometry and reduces crosstalk
• Jacket Thickness: 0.483 mm (0.019 in) for enhanced durability

Environmental Specifications

• Installation Temperature Range: 0°C to +60°C (+32°F to +140°F)
• Operating Temperature Range: -20°C to +60°C (-4°F to +140°F)
• Environmental Space: Plenum-rated
• Temperature Rating (ETL): 75°C (167°F)
• Flame Test Compliance: CMP/FT6, NEC Article 800, NFPA 262, UL 444, UL 910
• Smoke Test Method: CMP/FT6

Compliance & Certifications

The CommScope CS37P meets or exceeds numerous industry standards:

• Transmission Standards: ANSI/TIA-568.2-D, CENELEC EN 50288-6-1, ISO/IEC 11801 Class E
• ETL Verified: Ensures compliance with industry performance standards
• ISO 9001:2015: Designed and manufactured under this quality management system
• Safety Compliance: Meets all applicable fire and safety codes for plenum installations

Packaging Information

• Package Type: Reelex
• Cable Weight: 27.88 lb/kft (41.49 kg/km)

The CommScope CS37P represents the perfect combination of performance, reliability, and safety for your networking infrastructure. With its plenum rating and exceptional electrical characteristics, this cable ensures your network will perform optimally in even the most demanding environments.
